High quality engine ensures safer transportation

Hongyan Kingkan National Stage V series dump trucks can be matched with SAIC power system, and become the engine model of the world commercial vehicles in combination with the design of AVL, and meet the user demands such as high reliability, high efficiency, low fuel consumption, etc. With the mature National Stage V emissiontechnology, Hongyan Kingkan will be upgraded to National Stage VI. The advanced process is used for production, so that the quality is guaranteed.

SAIC power E series engines -- SC10E and SC12E, are combination of gold displacements of 10.4L and 11.8L. The bursting pressure is 20Mpa, and the power is instantaneously burst. At the same time, the latest Boschelectronically controlled high pressure common rail system, the straight six-cylinder and four-valve design, the integral cylinder cover, the clip type crankshaft front and rear oil seals, the cooling mode that the cylinder cover is cooled from top to bottom and other advanced technologies ensure the reliability and advancement of this series engine.

The engine has enough power and adapts to various road conditions

SAIC power E series engine has the maximum power of 460 horsepower and runs effortlessly. Its power will not be affected at all even in the climbing process or in other severe road conditions. The engine has low speed and high torque and easily deal with various road conditions. The maximum torque of SAIC power 12E series engine is up to 2200 N.m, and the torque of 800 RPM is more than 50% higher than that of the similar domestic engines. The engine has the characteristics of heavy load, fast start, short acceleration time, strong climbing and passing ability, good cold start capacity, no power loss in the plateau and adaption to various severe conditions.

At present, SAIC power E series engine has been validated through long-term use in various severe conditions, for example, Qamdo Iron Mine in Tibet at the altitude of 4,000 meters, Foshan Quarry in Guangdong with hot and humid climate, Wudongde Hydroelectric Power Station in lofty mountains and high ranges, reclamation works in Huanghua, Hebei Province, etc. In addition, E series electronic control engine is equipped with the integrated JACOBScylinder brake system, reducing 85% wheel braking requirement, shortening the braking distance, and reducing the times of treading the brake pedal, so that driving is safer.

Ultra-low fuel consumption, giving consideration to source development and expenditure reduction

SAIC power E series engine adopts the design of overhead cam, 24 valves, high bursting pressure and optimized combustion and has oil consumption 8-10% lower than that of the similar products at the same power. Not only the oil consumption is low, but also the maintenance cost is saved. The economy advantage of E series is prominent after it uses the centrifugal oil filter and the variable type oil pump.
